Today I want to switch gears and talk about the overlooked value of

A schematic diagram is a 'road map' of the hydraulic system and to a technician skilled in reading and interpreting hydraulic symbols, is a valuable aid in identifying possible causes of a problem.
This can save a lot of time and money when troubleshooting hydraulic problems.

If a schematic diagram is not available, the technician must trace the hydraulic circuit and identify its components in order to isolate
possible causes of the problem.

This can be a time-consuming process, depending on the complexity of the system. Worse still, if the circuit contains a valve manifold, the manifold may have to be removed and dismantled - just to establish what it's supposed to do. Reason being, if the function of a component within a hydraulic system is not known, it can be difficult to discount it as a possible cause of the problem.

The humble hydraulic symbol eliminates the need to 'reverse engineer' the hydraulic circuit.

As most hydraulic technicians know, there's usually a better than even chance that a schematic diagram will not be available for the machine they've been called in to troubleshoot. This is unlikely to bother the technician because it is the machine owner who pays for its absence.

Where do all the hydraulic schematic diagrams go?  They get lost or misplaced, they don't get transferred to the new owner
when a machine is bought secondhand and in some cases they may not be issued to the machine owner at all. Why? Because generally speaking, hydraulic equipment owners don't place a lot of value on them.

So if you're responsible for hydraulic equipment and you don't have schematic diagrams for your existing machines, try to obtain them - before you need them.  And ensure that you are issued with schematic diagrams for an additional hydraulic machines you acquire.

By Brendan Casey
